基于不同统计模型的肯尼亚滑坡危险性评价

周苏华; 付宇航; 邢静康; 彭爱泉; 蒋明奕

doi:10.16031/j.cnki.issn.1003-8035.202206006

基于不同统计模型的肯尼亚滑坡危险性评价

doi: 10.16031/j.cnki.issn.1003-8035.202206006

1.
湖南大学土木工程学院，湖南长沙　410006
2.
湖南大学建筑安全与节能教育部重点实验室，湖南长沙　410006
3.
贵州交通职业技术学院机械电子工程系，贵州贵阳　550081

基金项目: 国家自然科学基金青年基金项目（51708199） ;贵州省科技支撑计划项目（2020-4Y047） ;贵州省交通运输厅科技项目（2017-143-054）;福建省地质灾害重点实验室自主课题（KLGHZ202104）；创新平台与人才计划-湖湘高层次人才聚集工程-创新团队（2019RS1030）

详细信息

作者简介:
周苏华（1987-），男，江苏盐城人，副教授，博士，从事岩土工程风险评价研究。E-mail：zhousuhua@hnu.edu.cn

中图分类号: P642.22;
计量
- 文章访问数: 743
- HTML全文浏览量: 372
- PDF下载量: 22
- 被引次数: 0
出版历程
- 收稿日期: 2022-06-07
- 修回日期: 2022-09-30
- 网络出版日期: 2023-05-16

Assessment of landslide Hazard Risk in Kenya based on Different Statistical Models

1.
College of Civil Engineering, Hunan University, Changsha, Hunan　410006, China
2.
Key Laboratory of Building Safety and Energy Efficiency of the Ministry of Education, Changsha Hunan　410006, China
3.
Department of mechanical and electrical engineering, Guizhou Communications Polytechnic, Guiyang Guizhou　550081, China

摘要

摘要: 肯尼亚是我国“一带一路”倡议在东非重要支点。受高原裂谷地形和显著的雨旱季节影响，肯尼亚地质灾害频发。本文以肯尼亚的历史滑坡数据为样本，选取高度、坡度、坡向、地貌、平面曲率、土壤类型、年平均降雨量、水流强度指数、地形湿度指数及土地利用类型作为评价指标，分别基于信息量模型（IV）、逻辑回归模型（LR）和极限学习机模型（ELM）对肯尼亚滑坡灾害进行危险性区划，其中ELM分别考虑了SIG、SIN和HARDLIM函数作为激活函数进行讨论。主要结论如下：（1）肯尼亚滑坡灾害高危险性及以上等级区域集中分布在西南部的高原和高原-裂谷过渡地带；（2）采用ROC曲线对模型精度进行评价，各模型的AUC值分别为IV（0.977）、LR（0.965）、ELM-SIG（0.859）、ELM-SIN（0.900）、ELM-HARDLIM（0.941），评价结果有效；（3）综合PR曲线结果判定，LR模型的召回率和精确率都处于较高的水平，优于其他模型；（4）肯尼亚内罗毕省（Nairobi）、中部省（Central）、尼扬扎省（Nyanza）和西部省（Western）四个省份高危险性区域占比较大。
- 肯尼亚 /
- 危险性 /
- 信息量 /
- 逻辑回归 /
- 机器学习
Abstract: Kenya is an important fulcrum of China's Belt and Road Initiative in East Africa. However, due to its plateau rift terrain and aboriginal rain and drought season, geological disasters occur frequently in Kenya. The study used historical landslide data in Kenya as samples and selected several evaluation indexes, including elevation, slope, aspect, landform, plane curvature, soil type, annual average rainfall, stream power index, terrain witness index, and land use type. The landslide risk in Kenya was evaluated based on the information value model (IV), logistic regression model (LR), and extreme learning machine model (ELM), with the ELM model considering SIG, SIN, and HARDLIM functions as activation functions for discussion. The main findings are as follows: (1) The high-risk and above-grade areas of landslide disasters in Kenya are mainly concentrated in the plateau and plateau-rift transition zone in the southwest. (2) The ROC curve was used to evaluate the accuracy of the models, and the AUC values of the IV(0.977), LR(0.965), ELM-SIG(0.859), ELM-SIN(0.900), and ELM-HARDLIM(0.941) models illustrate their validity. (3) Considering the PR curve results comprehensively, the recall rate and precision rate of the LR model are at a high level, marking it better than other models. (4) Nairobi, Central, Nyanza and Western provinces in Kenya account for a significant proportion of the high-risk and above-grade areas of landslide disasters.
- Kenya /
- risk /
- information value /
- logistic regression /
- machine learning

HTML全文

图 1 肯尼亚概况

Figure 1. Distribution map of geological hazards in Kenya

下载: 全尺寸图片幻灯片

图 2 评价因素

Figure 2. Classification chart of each evaluation factor in Kenya

下载: 全尺寸图片幻灯片

图 3 神经网络结构示意图

Figure 3. Schematic diagram of neural network structure

下载: 全尺寸图片幻灯片

图 4 评价流程

Figure 4. Evaluation process chart

下载: 全尺寸图片幻灯片

图 5 极限学习机模型评价结果

Figure 5. Risk mapping evaluation results of the ELM model

下载: 全尺寸图片幻灯片

图 6 不同模型ROC曲线和PR曲线

Figure 6. Comparison of the ROC curves and PR curves for different models

下载: 全尺寸图片幻灯片

图 7 肯尼亚省份危险性区划分布

Figure 7. Distribution of province hazard zone in Kenya

下载: 全尺寸图片幻灯片

表 1 信息量模型系数

Table 1. Summary table for coefficients of the IV model

因素	因子分级	信息量	因素	因子分级	信息量
高程（m）	0−50	−1.341	坡度（°）	0−5	−2.212
	50−200	0.000		5−15	0.315
	200−500	−1.941		15−25	1.552
	500−1000	−2.813		25−35	3.671
	1000−2000	0.452		35−45	4.889
	>2000	2.316		>45	5.356
坡向	平	0.000	地貌	洼地	1.547
	北	0.282		山麓	0.340
	东北	0.322		高原	1.389
	东北	0.183		平原	−2.277
	东南	−0.032		谷底	0.000
	南	−0.215		悬崖	1.062
	西南	−0.707		丘陵	0.913
	西	−0.089		山谷	2.353
	西北	0.052		山脊	1.476
土壤类型	黏土	−0.124		水体	0.000
	壤土	0.115	年平均降雨量（mm）	<400	−1.762
	砂土	−1.948		400−800	−0.729
	高含量黏土	0.450		800−1200	0.850
TWI	7−12	1.666		1200−1600	2.240
	12−14	−1.423		1600−2000	0.503
	14−16	−2.041		2000-2400	0.607
	16−20	−1.785		>2400	0.000
	20−32	−2.319	SPI	2-5	−2.889
土地利用类型	农业用地	0.800		5−7	−1.562
	荒地	−1.365		7−9	0.972
	灌木丛	−1.570		9−12	1.107
	林地	2.043		12−23	0.250
	草地	0.000	平面曲率	凸	−0.089
	沼泽	0.000		平	−1.026
	城镇	2.148		凹	0.187

下载: 导出CSV

表 2 逻辑回归模型系数

Table 2. Summary table for coefficients of the LR model

因素	系数	因素	系数
高程	1.683	土壤类型	−0.048
坡度	0.754	TWI	−1.125
坡向	−0.097	SPI	1.481
地貌	0.229	年平均降雨量	1.466
平面曲率	0.047	土地利用类型	0.026

下载: 导出CSV

表 3 不同模型灾害分布统计结果

Table 3. Statistical results of disasters distribution for different models

危险性分区评估模型		极低危险性	低危险性	中危险性	高危险性	极高危险性
LR模型	面积占比	72.70%	11.90%	5.50%	4.40%	5.40%
	数量占比	2.57%	0.93%	1.17%	10.51%	84.81%
	灾害比重	0.035	0.078	0.213	2.389	15.705
IV模型	面积占比	35.30%	29.80%	16.90%	11.00%	6.90%
	数量占比	0.93%	0.93%	2.80%	17.52%	77.80%
	灾害比重	0.026	0.031	0.1657	1.593	11.275
ELM模型（SIG函数）	面积占比	1.30%	76.30%	19.40%	1.10%	1.90%
	数量占比	1.87%	8.41%	88.08%	1.17%	0.47%
	灾害比重	1.438	0.110	4.540	1.064	0.247
ELM模型（SIN函数）	面积占比	1.10%	38.30%	43.60%	12.80%	4.20%
	数量占比	0.70%	2.80%	9.11%	33.88%	53.50%
	灾害比重	0.636	0.073	0.208	2.647	12.738
ELM模型（HARDLIM函数）	面积占比	5.20%	34.30%	34.50%	18.00%	8.00%
	数量占比	0.93%	0.93%	2.80%	17.52%	77.80%
	灾害比重	0.178	0.027	0.081	0.973	9.725

下载: 导出CSV
